Press releases

The practical book for product managers in the B2B market

Every product manager or product owner wants their product to "fly" and hopes to find the blue ocean. But why is this rarely achieved? Often, assumptions are not solidly underpinned, risks are underestimated, initial situations are misjudged, products are not described in a future-proof way, the actual market positioning is missed or the real needs and wishes of the target group and their buying behavior are ignored.
The author presents an innovative method for effective strategy development that serves as a systematic stress test and allows product managers to recognize earlier how successful their product idea will be in practice.
The book is aimed at responsible product managers in the B2B sector and stakeholders such as marketing, sales and management who want to be faster and more successful. The forward-looking method described is suitable for both SMEs and start-ups. In addition to the theoretical background, the author systematically addresses each task in the entire product process, which is made up of the innovation and product life cycle process. He also provides product managers with specific tips, methods and tools for practical implementation. It takes a critical look at existing methods and adds important elements that need to be taken into account in our agile and fast-moving world.

More information (Springer Gabler Verlag)

Text and images (Wachendorff Prozesstechnik)
WP2410_Book_Robert_Wachendorff_The Product Manager and the Blue Sea_17102024-1.doc
WP2410_Book_Robert_Wachendorff_The_product_manager_and_the_Blue_Sea_17102024-1.pdf

Powerful panel PC and displays in a modern and robust design
Panel PC with extensive I/O expansion options

Wachendorff Prozesstechnik presents the brand new, fanless automation solution AUHMI from global supplier APLEX Technology Inc.

The AUHMI series comprises panel PCs (AUHMI-9) and displays (AUHMI-1), each in sizes from 10.1" to 21.5" TFT-LCD and IP66-certified front panel. The devices in the AUHMI series are powered by Intel Tiger Lake Core i3 and i5 of the 11th generation, which offer high computing power and very fast graphics processing. The devices support a sunlight readable solution for very bright working environments.

Elegant and robust design

Not only the outstanding computing power, but also the completely new, modern, elegant and robust design are impressive. A full-surface panel and an extremely slim frame made of die-cast aluminum are also characteristic features. Special fastening elements support installation and optimum positioning. In addition, the absence of mounting holes on the panel frame prevents dust from getting inside.

Extensive I/O expansion and communication diversity

AUHMI devices have various I/O interfaces. The AUHMI-1 series includes 1 x VGA, 1 x HDMI, 1 x DP port and OSD control. The AUHMI-9 series includes 4 x USB 3.0, 2 x GbE LAN, 1 x COM and 1 x DP/HDMI port. In addition, the panel PC also supports expansion cards, for example Mini-PCIe, COM, LAN, CAN BUS, Digital I/O, POE and USB ports.

AUHMI supports multiple internet connectivity such as Wi-Fi 6, Bluetooth, LTE, 5G and Giga LAN. Wi-Fi 6 significantly improves the overall performance and 5G accelerates the transmission speed. Therefore, AUHMI devices are the best choice to increase efficiency and they are especially suitable for smart manufacturing, factory automation, control and communication, SCADA and robotics applications, process control and so on.

Learn more

Image material (Wachendorff Prozesstechnik)
WP2306_PanelPC_Displays_AUHMI_11082023.doc
WP2306_PanelPC_Displays_AUHMI_11082023.pdf

PhanTAM series panel PCs
Waterproof stainless steel panel PCs
Stainless steel panel PC

Wachendorff Prozesstechnik has introduced the robust, waterproof stainless steel panel PCs of the PhanTAM series from APLEX Technology. The series improves the previous stainless steel solutions with an updated Intel 11th Gen. Core i3 (Dual Core) / i5 (Quad Core) BGA processor, an updated slim front bezel design, special hygienic screws on the rear housing, the ability to be used in landscape or portrait mode, and a waterproof antenna cover that eliminates the risk of bending/breaking antennas.

Like APLEX's ViTAM series, the PhanTAM series is designed for a wide range of hygienic industrial applications, including food and beverage manufacturing, the pharmaceutical industry and cleanrooms. The series features IP66 and IP69K certified protection with M12 connectors.

The fully enclosed 304 stainless steel, or optionally 316 stainless steel, housing is suitable for the food and beverage industry due to its sleek design, high corrosion resistance and germ resistance, helping to prevent any bacterial contamination.

The new hygienic screws with blue silicone rubber O-rings prevent the accumulation of water, dust and even bacteria, while offering flexible mounting options.

By adding waterproof antenna covers, users can utilize a range of antenna options (4G LTE, 5G, BT and Wi-Fi) and not have to worry about the antennas bending or breaking. This improves storage options and also makes cleaning easier.

Features include:

• DC 9~36 V wide range input
• 15.6″ and 21.5″ screen size available
• 11th Gen. Intel Core i3(Dual Core)/i5(Quad Core) processor
• supports up to 64 GB DDR4 RAM
• Wide temperature range: 0~50°C or -20~60°C

more information

Image material (Wachendorff Prozesstechnik)
WP2305_PanelPC_PhanTAM_16052023.doc
WP2305_PanelPC_PhanTAM_16052023.pdf

Optimized TV machine interface
Visualize data quickly and easily
Visualize clearly in optimal size

The cMT-FHDX-820 TV machine interface from Wachendorff Prozesstechnik is a simple and cost-effective solution for visualizing process data on commercially available TV and industrial touch monitors. The modified new device is characterized by a performance optimization that reduces the temperature during operation.

With its serial interfaces and integrated MPI interface, the TV machine interface is an optimal solution for brilliant visualizations on large screens.

• High-resolution HD 1080p HDMI output
• Quad-core Cortex-A17 CPU with high-performance 3D processor
• Supports user-defined resolutions for 16:9 / 4:3 LCD monitors.
• Supports MPI connection (187.5K)
• 1 Gigabit EtherNet connection
• Compact design and DIN rail mounting
• Integrated 4 GB flash memory and RTC real-time clock
• Integrated galvanic isolation of supply and system voltage

Further information

Image material (Wachendorff Prozesstechnik)
WP2304_TV-Machine-Interface_28022023.doc
WP2304_TV-Machine-Interface_28022023.pdf

Invitation to the webinar "Scalable Web HMI/Scada solution"
Software and hardware go hand in hand
Future-oriented operating concept meets high-performance hardware

A modern user interface is a very important sales argument for a machine. Web technology is the most future-oriented form: responsive, platform-independent, high-performance and accessible from a wide range of stationary and mobile devices from practically anywhere.

Two committed partners have joined forces to demonstrate how future-proof visualization can be set up in a targeted manner. And how software and hardware can complement each other perfectly: The companies Smart-HMI, with the intuitive Web HMI/Scada toolbox WebIQ, and Wachendorff, with a comprehensive range of powerful, robust industrial PCs for machines and systems.

Date: March 30, 2023, 11:00 a.m. to 12:00 p.m.

Speakers:
Egbert Gunia, Founder Smart-HMI & Robert Wachendorff, CEO Wachendorf

More information and registration at: https: //www.wachendorff-prozesstechnik.de/webinare

Image material (Wachendorff Prozesstechnik)
WP2302_Webinar_WebHMI_Loesung_28022023.doc
WP2302_Webinar_WebHMI_Loesung_28022023.pdf

Now even more powerful
Anti-reflection coating, optical bonding and high brightness
Panel PC with display sizes from 7" to 32"

The established, tried-and-tested Panel PC series ARCHMI (in aluminum housing) and ViTAM (in stainless steel housing) are now available with even more powerful processors and larger RAM - in the ARCHMI-9B and ViTAM-9B versions.
Users can configure their ideal Panel PC entirely according to their requirements: from the display size and processor to the size of the RAM memory and the communication interfaces. The Panel PCs are available in versions with projected capacitive touch, resistive touch or without touch. Display sizes from 7" to 32", in a wide range of formats from 4:3 to widescreen, leave nothing to be desired. With anti-reflection coating, optical bonding and high brightness, they are also ideal for use in difficult ambient conditions.

More information

Image material (Wachendorff Prozesstechnik)
WP2303_Performance_optimized_PanelPC_ARCHMI_ViTAM_28022023.doc
WP2303_Power_optimized_PanelPC_ARCHMI_ViTAM_28022023.pdf

Protocol converters for EtherCAT or EtherNet/IP
Convert protocols quickly and easily with gateways
Plant/machine modernization with gateways

Wachendorff Prozesstechnik's Gateway product portfolio continues to grow. The gateways for processing the Ethernet-based fieldbus protocols EtherCAT and EtherNet/IP are new additions to the product range. Different device designs, the wide temperature range, very simple configuration, installation and commissioning enable users to modernize systems and machines particularly cost-effectively.

• Bidirectional data exchange
• Wide temperature range from -40 °C to +85 °C
• Galvanic 3-way isolation
• Transmission of project planning via EtherNet

Further information

Image material (Wachendorff Prozesstechnik)
WP2301_Gateways_EtherCAT_EtherNetIP_28022023.doc
WP2301_Gateways_EtherCAT_EtherNetIP_28022023.pdf

Web panel with Linux, Android or AutomationBrowser

High-performance web panels ensure smooth operation

Brilliant visualization via web panel

The new HTLM5 web panel series from Wachendorff Prozesstechnik impresses with its brilliant display and very fast response during operation. Thanks to the IP65 protection class on the front and additional features such as WiFi, Bluetooth, USB and RS232, they are ideally equipped for almost all industrial applications.

Thanks to the display sizes from 7 inches to 23.8 inches and the different aspect ratios 4:3, 16.9, 16:9, users can find the optimum user interface for their machines and systems for every application.

• Very fast response thanks to Quadcore Cortex-A17/1.8 GHz CPU
• High performance thanks to 4 GB DDR3 DRAM and 32 GB eMMC
• Brilliant display with wide viewing angle
• Interfaces: WiFi, Bluetooth, USB, serial
• Protection class IP65, 12 VDC to 36 VDC
• Display sizes from 7" to 23.8"
• Aspect ratios 4:3, 16:9 and 16:10
• Display flush with frame
• Extensive customizing possible

Further information

Image material (Wachendorff Prozesstechnik)
WP2201_WebPanel_25082022.doc
WP2201_WebPanel_25082022.pdf

Exchanging information between EtherCAT and Modbus TPC, Profinet, CANopen

EtherCAT clients - such as a Beckhoff PLC or OMRON PLC - can be quickly and easily connected to a Modbus TCP client, Profinet master - e.g. a PLC, a SCADA system, etc. - to exchange information between networks. - to exchange information between the networks. On the EtherCAT side, there are two Ethernet ports for EtherCAT IN and OUT connections. These enable line and ring topology for simple redundant communication.

The EtherCAT Server Gateways can be integrated into the Master configuration thanks to the ESI file, which is created using the free configuration software.
The following devices are currently available:

• EtherCAT Server (Slave) / Modbus TCP Server (Slave)
• EtherCAT Server (Slave) / CANopen

EtherCAT Server (Slave) / Profinet Slave

Further information

Image material (Wachendorff Prozesstechnik)
WP2109_Wachendorff_EtherCAT_Gateways.doc
WP2109_Wachendorff_EtherCAT_Gateways.pdf

The clever solution
Maintenance-free and wear-free, over long distances

The Wireless Bolt, wireless access point and Client, can replace existing data transmission via moving parts such as slip rings, trolleys or even drag chains in cable replacement mode. The Wireless Bolt supports all common industrial protocols. Bluetooth is a very robust radio transmission technology for industrial applications with a range of up to 100 m; WLAN can be used as an alternative. The Wireless Bolt has an IP67 protection rating so that it can also be used in adverse environments. The Wireless Bolt supports operation as an Access Point or Client, allowing small networks to be set up as required.

Further information

Image material (Wachendorff Prozesstechnik)
WP2108_Wachendorff_WirelessBolt.doc
WP2108_Wachendorff_WirelessBolt.pdf

IO-Link Master modules

With the fieldbus-independent IO-Link interface, sensors and actuators can be connected to the control level via a cost-effective point-to-point connection. Wachendorff Prozesstechnik offers the right device / gateway for all common protocols, including Modbus RTU / TCP, BACnet, CAN, CANopen, J1939, EtherNet/IP, NMEA, MQTT, Profinet. The IO-Link Gateways operate in a wide temperature range from -40 °C to +85 °C. The Gateways are very easy to configure using free software. The project planning is transmitted via EtherNet.

Further information

Image material (Wachendorff Prozesstechnik)
WP2107_Wachendorff_IO_Link_Gateways.doc
WP2107_Wachendorff_IO_Link_Gateways.pdf

Customized IPC solutions
Always the optimal IPC solution

"Customizing, the individual adaptation of IPC to the respective customer-specific application, is becoming increasingly important as the level of integration increases and competitive pressure grows," says Florian Raupach, Product Manager at Wachendorff Prozesstechnik. "We have therefore specialized in customizing our proven IPC standard products to meet customer requirements. This allows us to define and implement optimal solutions for the user, even for smaller quantities." For example, the external appearance can be adapted to the customer's CI. Technical enhancements that go beyond the standard configuration are very often implemented, or the software required by the user is already installed before delivery, ensuring genuine plug & play.

More information

Image material (Wachendorff Prozesstechnik)
WP2106_Wachendorff_IPC_Customizing.doc
WP2106_Wachendorff_IPC_Customizing.pdf

Ergonomic machine operation and cloud connection
All-in-One HMI
Brilliant visualization

The All-in-One HMI cMT3161X turns machine operation into a real experience. The 15.6" full HD IPS display with 1920 x 1080 pixels and haptic feedback is one of the most brilliant devices on the market. The IIoT standard protocols OPC UA (Client) and MQTT enable communication between machines/plants and higher-level control/management systems. This ensures simultaneous monitoring and control of the transmission data.

Further information

Image material (Wachendorff Prozesstechnik)
WP2105_Wachendorff_All_in_one_HMI_cMT3161X.doc
WP2105_Wachendorff_All_in_one_HMI_cMT3161X.pdf

Powerful and robust industrial box PCs from the TiTAN series
Powerful, energy-saving and fail-safe

TiTAN industrial box PCs offer the right performance for every application. They have already proven themselves in many sectors in the industrial environment, including robotics, control technology and industrial automation. The high-quality aluminum housing and the components specially selected for fanless operation ensure reliable operation in continuous industrial operation. The high-performance industrial PCs in the TiTAN series can handle even the most demanding automation tasks. Very computationally intensive tasks, such as industrial 4K image and video processing, complex robot controls and extensive monitoring systems, are easy to implement

More information

Image material (Wachendorff Prozesstechnik)
WP2104_Wachendorff_TiTAN_BoxPC.doc
WP2104_Wachendorff_TiTAN_BoxPC.pdf

When hygiene is paramount
IPC with protection class IP66, IP69K
Industrial PC ViTAM and FABS, the hygiene professionals

Compliance with special hygiene standards is extremely important in many sectors, including the food industry. The IP66- and IP69K-certified IPCs in the ViTAM series are made of stainless steel and have a fully waterproof protective design that even allows them to be cleaned with a high-pressure cleaner or disinfectant during operation. The ViTAM series is also very easy to keep germ-free and is resistant to all intensive cleaning methods. It can be mounted with a wall bracket, an arm or on a stand. The panel PCs in the FABS series are certified to EN 1672-2, which means they meet the hygiene requirements of machines in food production and are primarily intended for panel mounting. These Panel PCs are also equipped with IP66 and IP69K protection on the front.

Further information

Image material (Wachendorff Prozesstechnik)
WP2103_Wachendorff_ViTAM_FABS_Hygiene.doc
WP2103_Wachendorff_ViTAM_FABS_Hygiene.pdf

Get started right away with the FREE package
Major update for the VISUALYS machine KPI dashboard

Since the beginning of February, another package has been available within the VISUALYS machine KPI dashboard for Ewon Flexy. The FREE package, with which users of the Ewon Flexy remote maintenance solution can generate a dashboard with up to 4 widgets free of charge. The FREE dashboard created free of charge can be downloaded directly and then installed and used on the Ewon Flexy VPN router. Every Ewon Flexy user - and those who want to become one - are welcome to create their own dashboard and use it permanently free of charge. More features and functions are then available in the SMART ROCKET packages.

Further information

Image material (Wachendorff Prozesstechnik)
WP2102_Wachendorff_FreePackage_KPI_Dashboard.doc
WP2102_Wachendorff_FreePackage_KPI_Dashboard.pdf

More than 315,000 integrated machines
A success story for 20 years - the Talk2M industrial cloud!

Ewon revolutionized the industry in 2001. The Ewon 4000 was launched: an innovative PLC remote access gateway based on Internet communication. The product and service portfolio has, of course, developed steadily in the meantime and takes into account - yesterday as well as today - all cyber security aspects in particular. Today, the focus is on high-performance, high-availability solutions for IIoT applications; remote access is mandatory. A big thank you to all users who have created something great with their trust and loyalty. Another milestone has been reached: more than 300,000 Ewon routers are now installed in the field worldwide, integrated into the secure and reliable Talk2M portal. We can rightly say that Talk2M is one of the most trusted and accepted IIoT solutions. We look forward to many more innovations in the coming years. More than ever, we need reliable networks that provide us with the information we need, when and where we need it. Wachendorff Prozesstechnik has been a reliable and competent sales partner since the early days and has established the Ewon & Talk2M remote maintenance solution in Germany.

More information

Image material (Wachendorff Prozesstechnik)
WP2101_Wachendorff_20years_Ewon_Talk2M.doc
WP2101_Wachendorff_20Years_Ewon_Talk2M.pdf

Xeo4 & VISUALYS announce partnership

Despite the coronavirus crisis, the German software company VISUALYS has announced a partnership with the Italian IIoT platform expert Xeo4. In the current corona situation, it is all the more important to make globally distributed machine data centrally available in one place.

Xeo4 is the developer and operator of the hardware-independent IIoT platform RILHEVA. With more than 15 years of experience in industry, energy and utilities, Xeo4 not only offers the right platform solution, but also experience in a wide range of applications and areas of use.

The contracts were signed by Robert Wachendorff, Managing Director of VISUALYS GmbH and Massimiliano Cravedi, Founder & Managing Director of Xeo4 - with sufficient safety distance, of course.

"For us, one of the most important aspects of the partnership is the fact that the platform is already mature, stable and has been continuously developed for years. Likewise, the cooperation and openness for further developments in the platform has been very good right from the start. Xeo4 contributes a wealth of experience and knowledge in the field of IIoT platforms, and we contribute our knowledge from the industry. Today, we can directly connect almost all communication devices in our portfolio and are now in a position to offer a hardware-independent IIoT platform for the German market," says Robert Wachendorff, describing this important step.

Massimiliano Cravedi is also aware of the benefits of this partnership:

"This partnership represents a big step for us. The German market is an important market for us and, together with our partner, we can now offer the right solution here too. Wachendorff has been one of the leading companies in the field of automation for more than 40 years and, with its own IIoT start-up, VISUALYS, is exactly the right partner. The level that Rilheva can provide is the final step in meeting the ultimate market requirements: An "end-to-end" turnkey solution. The mix of Wachendorff & VISUALYS' powerful IIoT platform and incredibly widespread customer base is great for us. Our entire team is looking forward to starting this new journey together in Germany!"

VISUALYS is thus continuing on its planned path. When the company was founded in summer 2019, it was already clear to the VISUALYS team that, in addition to the in-house development of the local machine KPI dashboard, there also had to be an advanced solution for centralized cloud-based data collection and processing. VISUALYS has therefore deliberately decided against another completely new development.

In this partnership, VISUALYS relies on the platform expertise of its colleagues from Italy and contributes the Wachendorff Group's many years of experience and know-how in automation technology.

Advantages of the VISUALYS IIoT platform

There are already over 500 IoT platforms of various types worldwide. On the one hand, there are the large telecommunications groups that are pushing into the industrial market and exploiting their advantages in communication, but of course do not necessarily have the experts in the field of mechanical and plant engineering. At the same time, there are the large technology groups, such as Amazon, Microsoft, HP, Cisco, etc., which provide platforms for in-house development and can also score points with their own analysis services. Furthermore, the major manufacturers of automation solutions are trying to combine customer loyalty and holistic integration from planning to project planning and service in one platform with their own platform offerings. The disadvantage here is that the integration of third-party hardware is virtually impossible or very difficult.

Last but not least, there are IIoT platform providers that focus on specific areas and industries and are experts in these fields. These include the VISUALYS IIoT platform, which focuses on mechanical and plant engineering and can connect almost all communication devices such as routers, IoT Gateways & Co via the standard protocols OPC UA, MQTT, Modbus, APIs etc. thanks to its hardware-independent platform. This enables VISUALYS GmbH to launch directly onto the market with a complete solution.

About VISUALYS GmbH

VISUALYS GmbH is the corporate start-up of the Wachendorff Group and focuses on the development, integration and consulting of software for Industry 4.0, SmartData and IIoT for machine and plant manufacturers and operators.

VISUALYS GmbH is based in the beautiful Rheingau region, near Frankfurt and Wiesbaden.

The Wachendorff Group has over 40 years of experience in the field of industrial automation technology. With Wachendorff Prozesstechnik GmbH & Co KG, as one of the leading providers of industrial remote maintenance solutions, operating devices & panel PCs and Gateways, VISUALYS quickly recognized that users are placing ever higher demands on data visualization and analysis over time.

Based on this, VISUALYS focuses exclusively on the topics of data analysis and visualization of machine data using the latest web technologies.

VISUALYS offers the user the right visualization and analysis concept from the multitude of solutions on offer based on our many years of experience. The offer currently includes a smart KPI dashboard for machine data visualization on smartphone & tablet, as well as an IIOT platform developed for the industry for central machine data acquisition and processing.

About Xeo4 s.r.l.

Xeo4 s.r.l., based in Piacenza (Italy), is the developer of the Rilheva IIoT platform since 2004. The Rilheva IIoT platform is the only one-stop cloud-based solution for the industry: no deployment time, no configuration time and the widest compatibility with Gateways and sensors. Rilheva offers all core Industrial Internet of Things functions: data acquisition, data storage and data processing.

More information about the dashboard and designer: www.visualys.net

Image material (VISUALYS GmbH):
VPM2002_E_Partnership_Rilheva_IIoT-Platform_September2020.doc
VPM2002_E_Partnership_Rilheva_IIoT-Platform_September2020.pdf

Expansion of the ViTAM series with displays
Displays in stainless steel housing
Displays for demanding environmental conditions

As an ideal addition to the ViTAM series panel PCs, the ViTAM displays now also impress with their modern, fanless stainless steel design and first-class workmanship. The front, which is visually identical to the IPC, enables seamless integration into the operating concept of the ViTAM series. Thanks to their closed housing and flush-mounted design, these displays are excellently protected against soiling and can be thoroughly cleaned very easily. Various options are available, such as projected capacitive touch with multi-touch support, optical bonding or high-brightness for outdoor use. This means that these displays can be used in a wide range of applications.

More information: https: //www.wachendorff-prozesstechnik.de/industrie-display-touch-vitam-serie/

Image material (Wachendorff Prozesstechnik):
WP2006_Wachendorff_ViTAM_Displays_05062020.doc
WP2006_Wachendorff_ViTAM_Displays_05062020.pdf

New generation of IPC devices with more computing power
Fast processors and powerful RAM
More computing power in the ARCHMI series IPCs

The IPCs in the ARCHMI series from Wachendorff have been given an attractive performance upgrade with the new generation of devices. With Intel® Celeron® and Pentium® up to 6th generation Core™ i processors, 16 GB DDR4 RAM memory and numerous expansion options, the ARCHMI series is equipped for very demanding hardware tasks. The retention of the proven external design and dimensions also makes it easy to add to and upgrade existing systems and installations.

More information: https://www.wachendorff-prozesstechnik.de/industrie-panel-pc-ipc-touch-archmi-serie/

Image material (Wachendorff Prozesstechnik):
WP2005_Wachendorff_PanelPC_ARCHMI-8A9A_05062020.doc
WP2005_Wachendorff_PanelPC_ARCHMI-8A9A_05062020.pdf

IPC series for increased hygiene requirements
IPC for the food and beverage industry
On the safe side with FABS

The extremely robust and powerful FABS series(FoodandBeverageSystem) from Wachendorff forms the perfect bridge between man and machine in very demanding hygienic environments. By complying with the DIN EN-1672-2 standard for the versions with/without projected capacitive touch screen, the IPCs in the FABS series are ideally suited for use in the food, beverage and tobacco industries, as well as in the pharmaceutical industry and other sensitive areas. This is made possible by an anti-scratch display, which fits perfectly into the stainless steel front panel and thus guarantees protection class IP66/69K. The FABS series is based on energy-efficient and powerful Intel® Celeron® to Core™ i processors and fast DDR4 RAM memory. There are also a wide range of expansion options, such as numerous I/O ports, WLAN or 4G. With display sizes between 7" and 21.5", they can be used in a wide range of applications.

More information: https://www.wachendorff-prozesstechnik.de/industrie-panel-pc-ipc-edelstahl-lebensmittelproduktion-fabs-serie/

Image material (Wachendorff Prozesstechnik):
WP2004_Wachendorff_IPC_FABS_15042020.doc
WP2004_Wachendorff_IPC_FABS_15042020.pdf

IPCs for every application
Robust, fanless industrial box PCs
Industrial PCs for a wide range of installation and performance requirements

The passively cooled, high-performance box PCs in the TiTAN series from Wachendorff make it easy to implement the extensive and real-time-capable control of machines and complex systems, including 4K image and video processing, as frequently required by Industry 4.0 applications. The efficient, space-saving cooling concept and the various housing designs for a wide range of installation situations also offer a decisive benefit. They enable flexible installation and ensure a long service life, even in demanding environments and in almost every field of application. Many individual customization options are available using expansion cards and slots.
They support the use of the latest communication technologies, such as WLAN, LTE and GPS, as well as integration into a wide range of systems. This is particularly interesting for remote monitoring, remote control and remote maintenance solutions.

More information:
https://www.wachendorff-prozesstechnik.de/panel-pc/informationen/box-pcs-der-titan-serie/

Image material (Wachendorff Prozesstechnik):
WP2003_Wachendorff_Box-PCs_30032020.doc
WP2003_Wachendorff_Box-PCs_30032020.pdf

Industrially robust touch displays from Wachendorff
Touch displays with 7 inch to 23.8 inch diagonals

The touch displays in the ARCDIS series from Wachendorff Prozesstechnik stand for brilliant visualization even under difficult lighting conditions.
They are available in sizes from 7 inches to 23.8 inches. Thanks to the fanless cooling system and a die-cast aluminum housing in IP66 design, they are ideally suited for demanding applications in industrial environments. The high-quality housing is flush with the front panel, making cleaning child's play. Numerous functions and options, such as projected capacitive touch display with multi-touch support, optical bonding or high brightness, enable use in a wide range of applications.

More information: www.wachendorff-prozesstechnik.de/arcdis

Image material (Wachendorff Prozesstechnik):
WP2002_Wachendorff_ARCDIS_TouchDisplays_17022020.doc
WP2002_Wachendorff_ARCDIS_TouchDisplays_17022020.pdf

No additional PLC hardware required

The cMT series HMIs from Wachendorff Prozesstechnik can be easily upgraded to a high-performance operating device with integrated CODESYS V3 control using a CODESYS activation card in conjunction with a license sticker.
No hardware modification is required for this.

The HMIs are based on an innovative architecture in which a duo-core CPU runs two independent operating systems. With the multi-core processor, the HMI is able to implement data visualization with an operable user interface and simultaneously operate the control logic. This means that the entire performance is available for the respective processes. HMI models with 7", 9.7" and 15" screen diagonals are available.

More information: www.wachendorff-prozesstechnik.de/WBGcMTCODESYS/

Image material (Wachendorff Prozesstechnik):
WP2001_Wachendorff_WBGcMT_Bediengerät_mit_CODESYS_SPS_31012020.doc
WP2001_Wachendorff_WBGcMT_Bediengerät_mit_CODESYS_SPS_31012020.pdf

Powerful, space-saving, user-friendly

Wachendorff presents the new G series of the FnIO functional I/O system. This series simplifies the acquisition of sensor/actuator data and provides communication to the PLC with over 10 different industrial protocols. With more than 80 different modules for inputs and outputs as well as special functions, users can configure their application-specific system as required and expand it at any time. The modular design of the G series makes it possible to simply transfer the I/O constellation required in the respective application centrally to a CODESYS controller or to implement it decentrally via a fieldbus node. The decentralized connection of the I/O modules works quickly and easily with the CODESYS controller from the G-series or the CODESYS+HMI controller solution from Wachendorff, but of course also via controllers from other manufacturers.
The optimized performance of the G-series offers, among other things, a higher IO and network scan frequency as well as a variety of industrial certifications, thus ensuring safe operation in often harsh industrial environments.

More information:
www.wachendorff-prozesstechnik.de/fnio

WP1919_Wachendorff_FnIO_SPS_IO_neue_Serie_06092019.doc
WP1919_Wachendorff_FnIO_SPS_IO_neue_Serie_06092019.pdf
