Field voltage:

5 VDC, 12 VDC, 24 VDC, 48 VDC, 115 VAC, 230 VAC

Current via contacts:

max. 10 A

Indicators:

1x green / red LED for module status

Power consumption:

18 mA at 5 VDC

Wiring:

I/O cable max. 2.0 mm²

Weight:

70 g

Operating temperature:

-20 °C to 60 °C

Storage temperature:

-45 °C to 85 °C

Relative humidity:

5 % to 90 % non-condensing

Dimensions (WxHxL):

12 mm x 99 mm x 70 mm

Connection technology:

Removable connection level (terminal blocks)

Vibration during operation:

10 g

Vibration during storage:

30 g

Vibration / shock resistance:

Tested axes: X, Y, Z
Displacement: 0.012 inch p-p from 10 Hz to 57 Hz
Acceleration: 2G's from 57 Hz to 500 Hz
Sweep rate: 1 octave / minute
Frequency sweeps per axis: 10

EMC:

EN 61000-6-2 Interference immunity, EN 61000-6-4 Emitted interference

Certificates:

CE, UL/cUL, LR
