Power supply:

via system voltage 5 VDC

Power consumption:

max. 45 mA at 5 VDC

Isolation:

I/O and logic: optocoupler
Field voltage: none

Field voltage:

Nominal voltage: 24 VDC typical
Voltage range: 11 VDC to 28.8 VDC
Power loss: max. 5 mA at 28.8 VDC per channel

Cross sections:

I/O cable max. 2 mm²

Connection technology:

Removable connection level (terminal blocks)

Dimensions (WxHxL):

12 mm x 99 mm x 70 mm

Operating temperature:

-20 °C to 50 °C

Operating altitude:

max. 2,000 m

Assembly:

DIN rail

Number of outputs:

4 channels, positive logic

Output voltage range:

24 VDC typical, 11 VDC to 28.8 VDC

Minimum current when switched through:

1 mA/channel

Output current:

max. 0.5 A/channel short-circuit proof, max. 2.0 A total

Diagnostic functions:

Short circuit, overload, overheating

Output protection:

Shutdown in case of overtemperature: min. 150 °C
Current limitation: min. 3.5 A, max. 7.5 A per channel
Short-circuit protection
ESD protection 5 KV
