Entrance:

0 VAC to 600 VAC, 45 Hz to 400 Hz with a resolution of 1 VAC.

Display:

3½-digit, 14 mm high LED.

Accuracy:

±0.1 % of the display + 2 digits at 23 °C

Maximum load:

- Indication of overrange by flashing of the last 3 digits
- Maximum input voltage 600 VA

Scaling:

If there is a linear relationship between the signal input voltage and the parameter, the devices can be scaled so that the parameter is displayed directly. For this purpose, the applied voltage is also fed via a potentiometer on the rear for fine adjustment. An automatic zero point correction takes place.

Measuring rate:

2.5 measurements/second

Decimal point setting:

The setting is made via 3 DIP switches located in the device.

Backlit unit:

With the label sheet, which contains all the usual units, the user can create the desired backlit unit. The backlighting is switched on and off via DIP switches.

Power supply:

115/230 VAC, 10 %, 50/60 Hz, 6 VA, switchable.

Protection class:

Jet-proof and dust-tight to IP65 from the front.

Housing

Robust plastic housing. W 97 mm x H 50 mm x D 104 mm

Panel cut-out:

DIN 92 mm x 45 mm

Fastening:

Via mounting frame with clamping screws

Ambient temperature:

Operation: 0 °C to +60 °C
Storage: -40 °C to +80 °C

Weight:

approx. 540 g

Scope of delivery:

Device, mounting material, seal, operating instructions

Customs tariff number:

9030 33 70

Manufacturer:

Red Lion Controls USA
