Voltmeter module MDMV
3 1/2 digit LCD display
Product discontinuation as of 31.12.2019.
- 3½-digit, 10 mm brilliant LCD display
- Input range up to +/- 200 mV
- Automatic zero point adjustment
- Freely selectable decimal point
- 5 different additional displays
Product discontinuation:
The voltmeter modules of the MDMV series were discontinued on 31.12.2019. The last possible date for ordering was 30.09.2019. We would be happy to advise you on alternatives.Please get in touchwith our application consultants.
The MDMV voltmeter module is available both for installation in a switch panel and for PCB mounting. An automatic zero point adjustment eliminates the need for manual adjustment of the zero point. The input range is +200 mVDC. If the range is exceeded or undershot, this is indicated on the display. The MDMV has 5 additional displays that can be shown independently of each other: BAT, V, A, m, µ. The high accuracy, small dimensions and very simple installation make the MDMV an interesting alternative to many conventional analog measuring devices.
Discontinued articles:
MDMV0000
MDMV for panel mounting, standard LCDMDMV0010
MDMV for panel mounting, green-yellow LCD digits- MDMV0020
MDMV for panel mounting, red LCD digits - MDMV0100
MDMV panel mount module, standard LCD - MDMV0110
MDMV board mounting module, green-yellow LCD digits - MDMV0120
MDMV board mounting module, red LCD digits
Accessories:
- HWK70000
Ribbon cable set with plug
Display
3½-digit, 10 mm high, brilliant LCD display, standard or with red or green/yellow LCD display. Minus (-) for negative input voltage. Input overrange is displayed ("1 "). Freely selectable decimal point.
Power supply
Standard LCD: 3VDC to 6 VDC, max. 500 µA;
with backlight: 4.8 to 6 VDC, max. 20mA.
Additional inserts
5 selectable overlays: BAT, V, A, m, µ. Activation via connection on the back.
Entrance
Display range +200 mVDC. Maximum input voltage: 6 VDC.
Miscellaneous
- Resolution: 100 µV
- Measuring rate: 400 ms
- Response time: 1.5 s
- Current consumption: typ. 1 pA, max. 10 pA
- Connection: connection pins
Housing
Plastic housing. MDMV for panel mounting: W 46 mm x H 27 mm x D 13 mm with red or green/yellow LCD or D 8 mm with standard LCD. Panel cut-out: 43 mm x 24 mm. Mounting via mounting frame. MDMV for PCB mounting: W 42 mm x H 23 mm x D 14 mm for red or green/yellow LCD or D 9 mm for standard LCD.
Ambient temperature
Operation: 0°C to +70°C.
Storage: -40°C to +80°C
Scope of delivery
Device, mounting material (MDMV for panel mounting), operating instructions.
Accessories
Ribbon cable set with plug.
