Power supply:

10 VDC to 30 VDC
A Class 2 circuit in accordance with the National Electrical Code (NEC) must be used,
NFPA-70 or Canadian Electrical Code (CEC), Part I, C22.1 or a limited power supply (LPS) according to
power supply (LPS) according to IEC 60950-1 or limited power supply
according to IEC 61010-1.

Battery: Lithium coin cell with a typical life of 5 years

Power connection

High-density cage clamp terminal strip
Cable stripping length: 7.5 mm
Conductor cross-section cable: 0.20 mm to 3.31 mm² (12 to 24 AWG) copper wire
Torque: 0.5 Nm to 0.6 Nm (4.4 inch-lbs to 5.3 inch-lbs)

Display:

7" 800 x 480 pixel TFT-LCD touch display in widescreen format with 16M colors.

Project planning:

Crimson 3.1 development platform

Integration skills:

• The Crimson 3.1 software enables configuration at the click of a mouse.
• Updated 3D icons and standard elements create a modern user experience.
• Ethernet, USB and serial interfaces make communication easy.
• Web server provides remote access and control to reduce costly site visits.
• Send email and/or SMS notifications for alarm conditions (expansion module required).
• Integrated data logging improves troubleshooting. Helps meet regulatory requirements.
• Automate the populating of data values with SQL query functions

Protocol conversion:

• Communication with over 300 protocols
• Easy conversion between serial, USB and Ethernet devices
• Convert up to 15 protocols simultaneously with the CR3000 series.
• Manage environments with devices from multiple vendors with ease.

Interfaces:

• USB ports:
  USB device:
  1x USB device
  Type B complies with USB specification 1.1
  USB host:
  2x USB host ports
  Type A complies with USB specification 2.0 and supports full speed.
  Data transfers with hardware overcurrent protection (max. 0.5 A per port)
• Serial ports for programming or communication:
  Format/baud rates independently configurable
  2x RS232 and 2x RS422/RS485
• Ethernet ports:
  1500 Vrms network isolation
  2x 10/100 BASE-T(X) connections (RJ45)

Network media:

10BaseT: > Cat3 cable
100BaseTX: > Cat5 cable

Protection class:

IP66 on the front, when mounted

Housing:

Polycarbonate housing with NEMA 4X/IP66 protection class for indoor use,
when properly fitted with the supplied gasket.
Installation category II, pollution degree 2.

Vibration:

2g at 5 Hz to 500 Hz according to IEC 68-2-6

Shock:

30g, IEC 68-2-27

Rel. humidity:

max. 85%. rH, non-condensing

Operating altitude:

Up to 2000 m

Operating temperature:

-10 °C to +50 °C

Storage temperature:

-20 °C to +70 °C

Weight:

913 g

Certificates:

CE-tested
Interference immunity: IEC/EN 61000-6-2 for industrial locations
Emissions: IEC/EN 6100-6-4 for industrial sites; CISPR 11 Class A
Safety: IEC/EN 61010-1
RoHS compliant
UL listed
Class I, Division 2, Groups A, B, C and D
Type 4X Indoor / IP66 protection class (front only)
